Главная Инструменты 201-05 - Parallelogram-shaped insert 800-12 T3 08M-C-G 1025

800-12 T3 08M-C-G 1025

Артикул: 5765199

В наличии

0 ₽

В корзину

Описание

Характеристики

AN (Clearance angle major)

17 Degree

CBMD (Chip breaker manufacturers designation)

CECC (Cutting edge condition code)

E - Rounded

COATN (Coating)

PVD TiCN+TiN

D1 (Fixing hole diameter)

2.8 mm

Delivery state

NL - Discontinued

Delivery state valid from

12/1/2023

DIN

SV-DF12T3C0

EPSR (Insert included angle)

85 Degree

GAN (Insert rake angle)

18 Degree

GRDMFG (Grade manufacturers designation)

1025

GRDPRIO (Standard designation of the grade main application)

IC (Inscribed circle diameter)

12.7 mm

IFS (Insert mounting style code)

3 - Counter bore for screws with taper angle from 40° to 60°

IH (Insert hand)

R - Right

Interface codes

J6 / J441

ISISO (ISO property)

ISO

SV$$DF12T3$$3RBC$$$

L (Cutting edge length)

12.7 mm

LOC-03 ISO

SV$$DF12T3$$3RBC$$$

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

SV-DF12T3C0

NOI (Insert index count)

RE (Corner radius)

0.8 mm

S (Insert thickness)

3.969 mm

S1 (Insert thickness total)

3.969 mm

TCE (Tipped cutting edge code)

TCINS (Tolerance class insert)

W1 (Insert width)

12.7 mm

Working process

No working processes available

WT (Weight of item)

0.006 kg
