Главная Инструменты 202-09 - Lay-down threading insert, triangle shape, three cutting edges, multiple teeth R166.39G-24RD03-100 4125

R166.39G-24RD03-100 4125

Артикул: 5742298

В наличии

0 ₽

В корзину

Описание

Характеристики

AN (Clearance angle major)

0 Degree

CBMD (Chip breaker manufacturers designation)

CECC (Cutting edge condition code)

E - Rounded

COATN (Coating)

PVD TiAlN+TiN

D1 (Fixing hole diameter)

4.675 mm

Delivery state valid from

12/1/2023

DIN

SV-TG24G000

GRDMFG (Grade manufacturers designation)

4125

GRDPRIO (Standard designation of the grade main application)

IFS (Insert mounting style code)

2 - With cylindrical bore

IH (Insert hand)

R - Right

INSL (Insert length)

24 mm

Interface codes

J6 / J61

ISO

SV$$TG24G$$$2RB$$$$

LOC-03 ISO

SV$$TG24G$$$2RB$$$$

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

SV-TG24G000

Materials

P,M,K,N,S

NOF (Flute count)

NT (Tooth count)

PAL (Profile angle left hand)

30 Degree

PAR (Profile angle right hand)

30 Degree

PDX (Profile distance X)

6.87 mm

PDY (Profile distance Y)

12.865 mm

PFS (Profile form)

S (Insert thickness)

6.35 mm

S1 (Insert thickness total)

6.35 mm

TCE (Tipped cutting edge code)

THFT (Thread form type)

APR60

TPIN (Threads per inch minimum)

TPT (Thread profile type)

V - Full profile

TTP (Thread type)

A - External thread

Working process

EGA - Threading, external

WT (Weight of item)

0.019 kg
