835.B-0800-A1-MF 1024
835.B-0800-A1-MF 1024
Артикул:
6267030
В наличии
0 ₽
Характеристики
APMX (Depth of cut maximum)
16 mm
BMC (Body material code)
H - Solid carbide
CNSC (Coolant entry style code)
1 - With Coolant entry, axial concentric
COATN (Coating)
PVD TiAlN
CXSC (Coolant exit style code)
1 - With Coolant exit, axial concentric
CXSC (Coolant exit style code) / Тип подвода СОЖ
1 - With Coolant exit, axial concentric
DC (Cutting diameter minimum)
8 mm
DCP (Data chip provision)
0 - Without data chip
Delivery state
LH - Stocked
Delivery state valid from
12/1/2023
DIN
ZYL00800115
DN (Neck diameter)
6.2 mm
FHA (Flute helix angle)
0 Degree
FHH (Flute helix hand)
N - Hand of helix neutral
GEP (Guide element property)
0 - Without guide elements
GRDMFG (Grade manufacturers designation)
1024
GRDPRIO (Standard designation of the grade main application)
HC
HAND (Cutting direction)
R - Right
Interface codes
J6 / J61
ISO
ZYL01F8000h$06
LF (Functional length)
98.8 mm
LOC-03 ISO
ZYL01F8000h$06
LOC-03 (CCFMS Connection code form)
01
LOC-03 (CCSMS Connection code style)
5 Shaft in machine direction or hole in workpiece direction
LOC-03 (CCTMS Connection code type)
ZYL cylindrical shank
LOC-03 (CCUMS Connection code unit base)
1 Metric with coolant
LOC-03 (CZCMS Connection size code)
0080
LOC-03 (DCONMS Diameter)
8 mm
LOC-03 (TCDCONCDMS Connection tolerance class coded)
h$06
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL00800115
LS (Shank length)
36 mm
LU (Usable length)
64 mm
Materials
M,S
NOF (Flute count)
6
OAL (Overall length)
100 mm
PLGL (Plug length)
1.2 mm
RPMX (Rotational speed maximum)
1910 1/min
SRR (Stock removal recommended)
0.3 mm
TCDCONMS (ISO-tolerance class shank diameter)
h6
TCDH (ISO tolerance class for drilling result)
H7
Working process
REI - Cylindrical reaming
WT (Weight of item)
0.065 kg
