L260.3-080M-10
L260.3-080M-10
Артикул:
5735003
В наличии
0 ₽
Характеристики
A1A (Cutting edge angle major Pos. A)
60 Degree
A2A (Clearance angle major Pos. A)
0 Degree
AZ (Plunge depth maximum)
0 mm
B3A (Inscribed circle diameter Pos. A)
12.7 mm
BD (Body diameter)
100.2 mm
BI (Block index)
1
BLDA (Tool style code Position A)
1
BMC (Body material code)
S - Solid steel
C1A (Insert thickness Pos. A)
4.762 mm
CCONMS (Connection count machine side)
2
CDX (Cutting depth maximum)
6 mm
CICT (Cutting item count)
10
CNSC (Coolant entry style code)
0 - Without coolant entry
CXSC (Coolant exit style code)
0 - Without coolant exit
CXSC (Coolant exit style code) / Тип подвода СОЖ
0 - Without coolant exit
D4A (Cutting edge angle major Pos. A)
45 Degree
DC (Cutting diameter)
80 mm
DCP (Data chip provision)
0 - Without data chip
DCX (Cutting diameter maximum)
92 mm
Delivery state
NL - Discontinued
Delivery state valid from
12/1/2023
DIN
FDA02701200
F23 (Number of mounting layers)
1
F24 (Cutting item count per mounting layer)
10
GAMF (Rake angle radial)
-7.76 Degree
GAMP (Rake angle axial)
-2.14 Degree
HAND (Cutting direction)
L - Left
Interface codes
J6 / J61
ISISO A (Indicator for ISO cutting plate Pos.A)
1
ISO
FDA12G2700$$$$
KAPR (Tool cutting edge angle)
45 Degree
LOC-03 ISO
FDA12G2700$$$$
LOC-03 (CCFMS Connection code form)
12
LOC-03 (CCSMS Connection code style)
0 Hole in machine direction or shaft in workpiece direction
LOC-03 (CCTMS Connection code type)
FDA Milling arbor mounting
LOC-03 (CCUMS Connection code unit base)
0 Metric
LOC-03 (CZCMS Connection size code)
0270
LOC-03 (DCONMS Diameter)
27 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
FDA02701200
MIID (Master insert identification)
TNEF1204AN
OAL (Overall length)
63 mm
RMPX (Ramping angle maximum)
0 Degree
RPMX (Rotational speed maximum)
1700 1/min
Working process
FPL - Face milling
WT (Weight of item)
3.12 kg
ZEFF (Face effective cutting edge count)
10
ZEFP (Peripheral effective cutting edge count)
10
