TPGX 28 07 16L-G 1125
TPGX 28 07 16L-G 1125
Артикул:
6332195
В наличии
0 ₽
Характеристики
AN (Clearance angle major)
11 Degree
CBMD (Chip breaker manufacturers designation)
G
CECC (Cutting edge condition code)
E - Rounded
COATN (Coating)
PVD TIALN+ALCR2O3
D1 (Fixing hole diameter)
5.5 mm
Delivery state
NL - Discontinued
Delivery state valid from
12/1/2023
DIN
SV-DM280700
EPSR (Insert included angle)
60 Degree
GAN (Insert rake angle)
0 Degree
GRDMFG (Grade manufacturers designation)
1125
GRDPRIO (Standard designation of the grade main application)
HC
IC (Inscribed circle diameter)
17 mm
IFS (Insert mounting style code)
3 - Counter bore for screws with taper angle from 40° to 60°
IH (Insert hand)
L - Left
Interface codes
J6 / J441
ISISO (ISO property)
1
ISO
SV$$DM2807$$3LB$$$$
L (Cutting edge length)
15.5 mm
LOC-03 ISO
SV$$DM2807$$3LB$$$$
LOC-03-Connection-codes
J6 / J441 - connection code machine end
LOC-03-DIN
SV-DM280700
MIID (Master insert identification)
TPGX280716 1125
NOI (Insert index count)
3
RE (Corner radius)
1.6 mm
S (Insert thickness)
7.57 mm
S1 (Insert thickness total)
7.57 mm
STDDES (Standard designation)
TPGX280716
TCE (Tipped cutting edge code)
S
TCINS (Tolerance class insert)
G
Working process
No working processes available
WT (Weight of item)
0.026 kg
