RCMT 08 03 MP-M3 1105
RCMT 08 03 MP-M3 1105
Артикул:
7960585
В наличии
0 ₽
Характеристики
AN (Clearance angle major)
7 Degree
CB (Chip breaker face count)
1 - With chip breaker one-side
CBMD (Chip breaker manufacturers designation)
M3
COATN (Coating)
PVD TiAlN
Delivery state
LH - Stocked
Delivery state valid from
12/1/2023
DIN
RC0803M03N
GRDMFG (Grade manufacturers designation)
1105
GRDPRIO (Standard designation of the grade main application)
HC
IC (Inscribed circle diameter)
8 mm
IFS (Insert mounting style code)
3 - Counter bore for screws with taper angle from 40° to 60°
IH (Insert hand)
N - Neutral
Interface codes
J6 / J441
ISISO (ISO property)
ISO
ISO$RC0803M03NBZ$M0
LOC-03 ISO
ISO$RC0803M03NBZ$M0
LOC-03-Connection-codes
J6 / J441 - connection code machine end
LOC-03-DIN
RC0803M03N
M (M-dimension)
8 mm
Materials
P,M,S
S (Insert thickness)
3.175 mm
S1 (Insert thickness total)
3.175 mm
TCE (Tipped cutting edge code)
S
TCINS (Tolerance class insert)
M
Working process
No working processes available
WT (Weight of item)
0.002 kg
