Главная Инструменты 201-00 - Regular Insert unspecified 745R-2109E-H50 4330

745R-2109E-H50 4330

Артикул: 7564454

В наличии

0 ₽

В корзину

Описание

Характеристики

AN (Clearance angle major)

13 Degree

BN (Face land width)

0.4 mm

BS (Wiper edge length)

0.3 mm

CBMD (Chip breaker manufacturers designation)

H50

CECC (Cutting edge condition code)

S - Chamfered and rounded

CHW (Corner chamfer width)

1 mm

COATN (Coating)

CVD TICN+AL2O3+TIN

D1 (Fixing hole diameter)

8.3 mm

Delivery state

NL - Discontinued

Delivery state valid from

12/1/2023

DIN

SV-NN210900

EPSR (Insert included angle)

128.571 Degree

GAN (Insert rake angle)

44 Degree

GB (Face land angle)

-16 Degree

GRDMFG (Grade manufacturers designation)

4330

GRDPRIO (Standard designation of the grade main application)

IC (Inscribed circle diameter)

21 mm

IFS (Insert mounting style code)

3 - Counter bore for screws with taper angle from 40° to 60°

IH (Insert hand)

R - Right

Interface codes

J6 / J441

ISISO (ISO property)

ISO

SV$$NN2109$$3RB$$$$

KCH (Corner chamfer angle)

17 Degree

KRINS (Cutting edge angle major)

42 Degree

L (Cutting edge length)

10.113 mm

LE (Cutting edge effective length)

8.9 mm

LOC-03 ISO

SV$$NN2109$$3RB$$$$

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

SV-NN210900

RE (Corner radius)

1 mm

S (Insert thickness)

9 mm

S1 (Insert thickness total)

9 mm

TCE (Tipped cutting edge code)

TCINS (Tolerance class insert)

Working process

No working processes available

WT (Weight of item)

0.033 kg
