393.14-20 D060X049
393.14-20 D060X049
Артикул:
5760406
В наличии
0 ₽
Характеристики
BD (Body diameter)
21 mm
CCFWS (Connection code form)
21
CCSWS (Connection code style)
5
CCTWS (Connection code type)
ZYL
CCUWS (Connection code unit base)
1
CZCWS (Connection size code)
0060
Delivery state
LH - Stocked
Delivery state valid from
12/1/2023
DIN
SZD02000295
Interface codes
J6 / J61
ISO
SZD02C0200$$$$
LCOL (Collet length)
23.9 mm
LOC-01 ISO
ZYL21F6000****
LOC-01 (CCFWS Connection code form)
21
LOC-01 (CCSWS Connection code style)
5 Shaft in machine direction or hole in workpiece direction
LOC-01 (CCTWS Connection code type)
ZYL cylindrical shank
LOC-01 (CCUWS Connection code unit base)
1 Metric with coolant
LOC-01 (CZCWS Connection size code)
0060
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
ZYL00602115
LOC-02 ISO
ZYL21R2362****
LOC-02 (CCFWS Connection code form)
21
LOC-02 (CCSWS Connection code style)
5 Shaft in machine direction or hole in workpiece direction
LOC-02 (CCTWS Connection code type)
ZYL cylindrical shank
LOC-02 (CCUWS Connection code unit base)
1 Metric with coolant
LOC-02 (CZCWS Connection size code)
0060
LOC-02-Connection-codes
J4 / J431 - Workpiece end
LOC-02-DIN
ZYL02362135
LOC-03 ISO
SZD02C0200$$$$
LOC-03 (CCFMS Connection code form)
02
LOC-03 (CCSMS Connection code style)
5 Shaft in machine direction or hole in workpiece direction
LOC-03 (CCTMS Connection code type)
SZD Collet adapter DIN / ISO
LOC-03 (CCUMS Connection code unit base)
9 non-dimensional size with coolant
LOC-03 (CZCMS Connection size code)
0200
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
SZD02000295
LSCX (Clamping length maximum)
18 mm
OAL (Overall length)
31.5 mm
SEALP (Sealing)
1 - With sealing
WT (Weight of item)
0.042 kg
