HA06-AWE09-B030-075
HA06-AWE09-B030-075
Артикул:
8330738
В наличии
0 ₽
Характеристики
BD (Body diameter 2)
29.5 mm
BD (Body diameter)
29.46 mm
BLDEV (Balancing device)
1
CCFWS (Connection code form)
10
CCSWS (Connection code style)
5
CCTWS (Connection code type)
ZYL
CCUWS (Connection code unit base)
3
CNSC (Coolant entry style code)
1 - With Coolant entry, axial concentric
CXSC (Coolant exit style code)
4 - With Coolant exit, axial on hole circle
CXSC (Coolant exit style code) / Тип подвода СОЖ
4 - With Coolant exit, axial on hole circle
CZCWS (Connection size code)
0375
DCINTF (Interference cutting diameter)
20.8 mm
DCONWS (Diameter)
9.525 mm
DCONWS (Diameter) / Диаметр соединения со стороны заготовки
9.525 mm
DCP (Data chip provision)
1 - With data chip
Delivery state
LH - Stocked
Delivery state valid from
6/1/2024
DIN
HSK06300195
HAND (Cutting direction)
N - Neutral
Interface codes
J6 / J61
ISO
HSK01C0630$$$$
LB (Body length 1)
7.5 mm
LB (Length 2)
36.5 mm
LF (Functional length)
75 mm
LOC-01 ISO
ZYL18F9525****
LOC-01 (CCFWS Connection code form)
10
LOC-01 (CCSWS Connection code style)
5 Shaft in machine direction or hole in workpiece direction
LOC-01 (CCTWS Connection code type)
ZYL cylindrical shank
LOC-01 (CCUWS Connection code unit base)
3 Inch with coolant
LOC-01 (CZCWS Connection size code)
0375
LOC-01 (DCONWS Diameter)
9.525 mm
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
ZYL03751035
LOC-02 ISO
ZYL10F9525****
LOC-02 (CCFWS Connection code form)
10
LOC-02 (CCSWS Connection code style)
5 Shaft in machine direction or hole in workpiece direction
LOC-02 (CCTWS Connection code type)
ZYL cylindrical shank
LOC-02 (CCUWS Connection code unit base)
3 Inch with coolant
LOC-02 (CZCWS Connection size code)
0375
LOC-02 (DCONWS Diameter)
9.525 mm
LOC-02-Connection-codes
J4 / J431 - Workpiece end
LOC-02-DIN
ZYL00951015
LOC-03 ISO
HSK01C0630$$$$
LOC-03 (CCFMS Connection code form)
01
LOC-03 (CCSMS Connection code style)
5 Shaft in machine direction or hole in workpiece direction
LOC-03 (CCTMS Connection code type)
HSK Hollow taper shank
LOC-03 (CCUMS Connection code unit base)
9 non-dimensional size with coolant
LOC-03 (CZCMS Connection size code)
0630
LOC-03 (DCONMS Diameter)
63 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
HSK06300195
LPR (Protruding length)
75 mm
OAL (Overall length)
106.9 mm
RPMX (Rotational speed maximum)
20500 1/min
TA (Taper angle)
30 Degree
WT (Weight of item)
0.845 kg
