Главная Инструменты 401-01 - Converter, rotationally symmetric EH12-A11.7-SH-135

EH12-A11.7-SH-135

Артикул: 6854902

В наличии

0 ₽

В корзину

Описание

Характеристики

BD (Body diameter)

11.7 mm

BLDEV (Balancing device)

CCFWS (Connection code form)

CCSWS (Connection code style)

CCTWS (Connection code type)

SAC

CCUWS (Connection code unit base)

CNSC (Coolant entry style code)

1 - With Coolant entry, axial concentric

CXSC (Coolant exit style code)

1 - With Coolant exit, axial concentric

CXSC (Coolant exit style code) / Тип подвода СОЖ

1 - With Coolant exit, axial concentric

CZCWS (Connection size code)

0120

DCONWS (Diameter)

11.7 mm

DCONWS (Diameter) / Диаметр соединения со стороны заготовки

11.7 mm

DCP (Data chip provision)

0 - Without data chip

Delivery state valid from

12/1/2023

DIN

ZYL01170115

HAND (Cutting direction)

R - Right

Interface codes

J6 / J61

ISO

ZYL01G1170$$$$

LB (Body length 1)

135 mm

LF (Functional length)

135 mm

LOC-01 (CCFWS Connection code form)

LOC-01 (CCSWS Connection code style)

5 Shaft in machine direction or hole in workpiece direction

LOC-01 (CCTWS Connection code type)

SAC Screw mounting SANDVIK Coromant

LOC-01 (CCUWS Connection code unit base)

1 Metric with coolant

LOC-01 (CZCWS Connection size code)

0120

LOC-01 (DCONWS Diameter)

11.7 mm

LOC-01-Connection-codes

J4 / J431 - Workpiece end

LOC-01-DIN

SAC01200415

LOC-02 ISO

SAC04B0120****

LOC-02 (DCONWS Diameter)

11.7 mm

LOC-02-Connection-codes

J4 / J431 - Workpiece end

LOC-03 ISO

ZYL01G1170$$$$

LOC-03 (CCFMS Connection code form)

LOC-03 (CCSMS Connection code style)

5 Shaft in machine direction or hole in workpiece direction

LOC-03 (CCTMS Connection code type)

ZYL cylindrical shank

LOC-03 (CCUMS Connection code unit base)

1 Metric with coolant

LOC-03 (CZCMS Connection size code)

0117

LOC-03 (DCONMS Diameter)

11.7 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL01170115

LPR (Protruding length)

94 mm

LS (Shank length)

132 mm

LSCX (Clamping length maximum)

132 mm

OAL (Overall length)

135 mm

RPMX (Rotational speed maximum)

17000 1/min

WT (Weight of item)

0.29 kg
