C8-391.05-22 030M
C8-391.05-22 030M
Артикул:
6228935
В наличии
0 ₽
Характеристики
BD (Body diameter)
80 mm
BLDEV (Balancing device)
CCFWS (Connection code form)
12
CCSWS (Connection code style)
CCTWS (Connection code type)
FDA
CCUWS (Connection code unit base)
1
CNSC (Coolant entry style code)
3 - With Coolant entry, axial concentric and radial
CXSC (Coolant exit style code)
1 - With Coolant exit, axial concentric
CXSC (Coolant exit style code) / Тип подвода СОЖ
1 - With Coolant exit, axial concentric
CZCWS (Connection size code)
0220
DCONWS (Diameter)
22 mm
DCONWS (Diameter) / Диаметр соединения со стороны заготовки
22 mm
DCP (Data chip provision)
0 - Without data chip
Delivery state
NL - Discontinued
Delivery state valid from
12/1/2023
DIN
CCS08000195
HAND (Cutting direction)
N - Neutral
Interface codes
J6 / J61
ISO
CCS01C0800$$$$
LB (Body length 1)
30 mm
LF (Functional length)
30 mm
LOC-01 (CCFWS Connection code form)
12
LOC-01 (CCSWS Connection code style)
0 Hole in machine direction or shaft in workpiece direction
LOC-01 (CCTWS Connection code type)
FDA Milling arbor mounting
LOC-01 (CCUWS Connection code unit base)
1 Metric with coolant
LOC-01 (CZCWS Connection size code)
0220
LOC-01 (DCONWS Diameter)
22 mm
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
FDA02201210
LOC-02 ISO
FDA22G2200****
LOC-02 (DCONWS Diameter)
22 mm
LOC-02-Connection-codes
J4 / J431 - Workpiece end
LOC-03 ISO
CCS01C0800$$$$
LOC-03 (CCFMS Connection code form)
01
LOC-03 (CCSMS Connection code style)
5 Shaft in machine direction or hole in workpiece direction
LOC-03 (CCTMS Connection code type)
CCS Coromant Capto System SANDVIK
LOC-03 (CCUMS Connection code unit base)
9 non-dimensional size with coolant
LOC-03 (CZCMS Connection size code)
0800
LOC-03 (DCONMS Diameter)
80 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
CCS08000195
OAL (Overall length)
78 mm
Rotation (Rotation indicator)
1 - rotating tool
WT (Weight of item)
1.881 kg
