Главная Инструменты 401-01 - Converter, rotationally symmetric 392.EREH-25 20 019

392.EREH-25 20 019

392.EREH-25 20 019 392.EREH-25 20 019 392.EREH-25 20 019 392.EREH-25 20 019

392.EREH-25 20 019

SV - Sandvik-Coromant
Артикул: 6048679
В наличии
0 ₽
В корзину
Описание
Характеристики
BD (Body diameter)
19.2 mm
BLDEV (Balancing device)
1
CCFWS (Connection code form)
04
CCSWS (Connection code style)
5
CCTWS (Connection code type)
SAC
CCUWS (Connection code unit base)
1
CNSC (Coolant entry style code)
1 - With Coolant entry, axial concentric
CXSC (Coolant exit style code)
1 - With Coolant exit, axial concentric
CXSC (Coolant exit style code) / Тип подвода СОЖ
1 - With Coolant exit, axial concentric
CZCWS (Connection size code)
0200
DCONWS (Diameter)
26 mm
DCONWS (Diameter) / Диаметр соединения со стороны заготовки
26 mm
DCP (Data chip provision)
0 - Without data chip
Delivery state
LH - Stocked
Delivery state valid from
12/1/2023
DIN
SZD02500295
HAND (Cutting direction)
R - Right
Interface codes
J6 / J61
ISO
SZD02C0250$$$$
LB (Body length 1)
19 mm
LF (Functional length)
29.1 mm
LOC-01 ISO
SAC04A0200****
LOC-01 (CCFWS Connection code form)
04
LOC-01 (CCSWS Connection code style)
5 Shaft in machine direction or hole in workpiece direction
LOC-01 (CCTWS Connection code type)
SAC Screw mounting SANDVIK Coromant
LOC-01 (CCUWS Connection code unit base)
1 Metric with coolant
LOC-01 (CZCWS Connection size code)
0200
LOC-01 (DCONWS Diameter)
26 mm
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
SAC02000415
LOC-03 ISO
SZD02C0250$$$$
LOC-03 (CCFMS Connection code form)
02
LOC-03 (CCSMS Connection code style)
5 Shaft in machine direction or hole in workpiece direction
LOC-03 (CCTMS Connection code type)
SZD Collet adapter DIN / ISO
LOC-03 (CCUMS Connection code unit base)
9 non-dimensional size with coolant
LOC-03 (CZCMS Connection size code)
0250
LOC-03 (DCONMS Diameter)
26 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
SZD02500295
LPR (Protruding length)
29.1 mm
OAL (Overall length)
56.2 mm
RPMX (Rotational speed maximum)
40000 1/min
WT (Weight of item)
0.226 kg
