Главная Инструменты 401-01 - Converter, rotationally symmetric 392.55T-40 10 058

392.55T-40 10 058

392.55T-40 10 058 392.55T-40 10 058 392.55T-40 10 058

392.55T-40 10 058

SV - Sandvik-Coromant
Артикул: 5760079
В наличии
0 ₽
В корзину
Описание
Характеристики
BD (Body diameter 2)
20 mm
BD (Body diameter)
19.998 mm
BLDEV (Balancing device)
CCFWS (Connection code form)
03
CCSWS (Connection code style)
5
CCTWS (Connection code type)
SAC
CCUWS (Connection code unit base)
1
CNSC (Coolant entry style code)
1 - With Coolant entry, axial concentric
CXSC (Coolant exit style code)
1 - With Coolant exit, axial concentric
CXSC (Coolant exit style code) / Тип подвода СОЖ
1 - With Coolant exit, axial concentric
CZCWS (Connection size code)
0100
DCINTF (Interference cutting diameter)
17.8 mm
DCP (Data chip provision)
0 - Without data chip
Delivery state
LA - Soon discontinued
Delivery state valid from
12/1/2023
DF (Flange diameter)
63 mm
DIN
SKG04005195
HAND (Cutting direction)
R - Right
Interface codes
J6 / J61
ISO
SKG51C0400$$$$
LB (Body length 1)
24.2 mm
LB (Length 2)
6.8 mm
LF (Functional length)
58 mm
LOC-01 ISO
SAC03A0100****
LOC-01 (CCFWS Connection code form)
03
LOC-01 (CCSWS Connection code style)
5 Shaft in machine direction or hole in workpiece direction
LOC-01 (CCTWS Connection code type)
SAC Screw mounting SANDVIK Coromant
LOC-01 (CCUWS Connection code unit base)
1 Metric with coolant
LOC-01 (CZCWS Connection size code)
0100
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
SAC01000315
LOC-03 ISO
SKG51C0400$$$$
LOC-03 (CCFMS Connection code form)
51
LOC-03 (CCSMS Connection code style)
5 Shaft in machine direction or hole in workpiece direction
LOC-03 (CCTMS Connection code type)
SKG steep taper shank
LOC-03 (CCUMS Connection code unit base)
9 non-dimensional size with coolant
LOC-03 (CZCMS Connection size code)
0400
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
SKG04005195
LPR (Protruding length)
58 mm
OAL (Overall length)
126.4 mm
TA (Taper angle)
2.6 Degree
WT (Weight of item)
1.059 kg
