392.410277-100 02 065A
392.410277-100 02 065A
Артикул:
5759952
В наличии
0 ₽
Характеристики
BD (Body diameter)
106 mm
BLDEV (Balancing device)
CCFWS (Connection code form)
08
CCSWS (Connection code style)
5
CCTWS (Connection code type)
PMC
CCUWS (Connection code unit base)
9
CNSC (Coolant entry style code)
1 - With Coolant entry, axial concentric
CXSC (Coolant exit style code)
1 - With Coolant exit, axial concentric
CXSC (Coolant exit style code) / Тип подвода СОЖ
1 - With Coolant exit, axial concentric
CZCWS (Connection size code)
0980
DCONWS (Diameter)
100 mm
DCONWS (Diameter) / Диаметр соединения со стороны заготовки
100 mm
DCP (Data chip provision)
0 - Without data chip
Delivery state
LA - Soon discontinued
Delivery state valid from
12/1/2023
DIN
HSK10000195
HAND (Cutting direction)
N - Neutral
Interface codes
J6 / J61
ISO
HSK01C1000$$$$
LB (Body length 1)
60.6 mm
LF (Functional length)
65 mm
LOC-01 ISO
PMC08C0980****
LOC-01 (CCFWS Connection code form)
08
LOC-01 (CCSWS Connection code style)
5 Shaft in machine direction or hole in workpiece direction
LOC-01 (CCTWS Connection code type)
PMC Prism mounting SANDVIK Coromant
LOC-01 (CCUWS Connection code unit base)
9 non-dimensional size with coolant
LOC-01 (CZCWS Connection size code)
0980
LOC-01 (DCONWS Diameter)
100 mm
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
PMC09800895
LOC-03 ISO
HSK01C1000$$$$
LOC-03 (CCFMS Connection code form)
01
LOC-03 (CCSMS Connection code style)
5 Shaft in machine direction or hole in workpiece direction
LOC-03 (CCTMS Connection code type)
HSK Hollow taper shank
LOC-03 (CCUMS Connection code unit base)
9 non-dimensional size with coolant
LOC-03 (CZCMS Connection size code)
1000
LOC-03 (DCONMS Diameter)
100 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
HSK10000195
LPR (Protruding length)
65 mm
OAL (Overall length)
139.6 mm
RPMX (Rotational speed maximum)
9000 1/min
WT (Weight of item)
4.525 kg
