Главная Инструменты 401-02 - Converter, stationary MB-A0625-08-09L-HP

MB-A0625-08-09L-HP

Артикул: 6350771

В наличии

0 ₽

В корзину

Описание

Характеристики

BD (Body diameter)

9 mm

CCFWS (Connection code form)

CCSWS (Connection code style)

CCTWS (Connection code type)

BKC

CCUWS (Connection code unit base)

CNSC (Coolant entry style code)

1 - With Coolant entry, axial concentric

CXSC (Coolant exit style code)

1 - With Coolant exit, axial concentric

CXSC (Coolant exit style code) / Тип подвода СОЖ

1 - With Coolant exit, axial concentric

CZCWS (Connection size code)

0090

DCONWS (Diameter)

15.875 mm

DCONWS (Diameter) / Диаметр соединения со стороны заготовки

15.875 mm

DCP (Data chip provision)

0 - Without data chip

Delivery state valid from

12/1/2023

DIN

ZYL06252235

HAND (Cutting direction)

L - Left

HF (Functional height)

0 mm

Interface codes

J6 / J61

ISO

ZYL22R6250$$$$

LB (Body length 1)

20 mm

LF (Functional length)

74.7 mm

LOC-01 ISO

BKC01C0090****

LOC-01 (CCFWS Connection code form)

LOC-01 (CCSWS Connection code style)

5 Shaft in machine direction or hole in workpiece direction

LOC-01 (CCTWS Connection code type)

BKC drill head mounting SANDVIK Coromant

LOC-01 (CCUWS Connection code unit base)

9 non-dimensional size with coolant

LOC-01 (CZCWS Connection size code)

0090

LOC-01 (DCONWS Diameter)

15.875 mm

LOC-01-Connection-codes

J4 / J431 - Workpiece end

LOC-01-DIN

BKC00900195

LOC-02 ISO

BKC01CF09L****

LOC-02 (CCFWS Connection code form)

LOC-02 (CCSWS Connection code style)

5 Shaft in machine direction or hole in workpiece direction

LOC-02 (CCTWS Connection code type)

BKC drill head mounting SANDVIK Coromant

LOC-02 (CCUWS Connection code unit base)

9 non-dimensional size with coolant

LOC-02 (CZCWS Connection size code)

0090

LOC-02 (DCONWS Diameter)

15.875 mm

LOC-02-Connection-codes

J4 / J431 - Workpiece end

LOC-02-DIN

BKCF09L0195

LOC-03 ISO

ZYL22R6250$$$$

LOC-03 (CCFMS Connection code form)

LOC-03 (CCSMS Connection code style)

5 Shaft in machine direction or hole in workpiece direction

LOC-03 (CCTMS Connection code type)

ZYL cylindrical shank

LOC-03 (CCUMS Connection code unit base)

3 Inch with coolant

LOC-03 (CZCMS Connection size code)

0625

LOC-03 (DCONMS Diameter)

15.875 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL06252235

LPR (Protruding length)

20 mm

LS (Shank length)

54 mm

LSCX (Clamping length maximum)

54 mm

OAL (Overall length)

74.7 mm

WF (Functional width)

0 mm

WT (Weight of item)

0.128 kg
