C3-DNI-IX30A-I
C3-DNI-IX30A-I
Артикул:
8094142
В наличии
0 ₽
Характеристики
CCFWS (Connection code form)
01
CCSWS (Connection code style)
5
CCTWS (Connection code type)
CCS
CCUWS (Connection code unit base)
9
CNSC (Coolant entry style code)
7 - Coolant entry, decentral and axially concentric
CXSC (Coolant exit style code)
1 - With Coolant exit, axial concentric
CXSC (Coolant exit style code) / Тип подвода СОЖ
1 - With Coolant exit, axial concentric
CZCWS (Connection size code)
0320
DCONWS (Diameter)
32 mm
DCONWS (Diameter) / Диаметр соединения со стороны заготовки
32 mm
DCP (Data chip provision)
0 - Without data chip
Delivery state valid from
12/1/2023
DIN
FLCQ3AD0295
HAND (Cutting direction)
N - Neutral
HF (Functional height)
0 mm
Interface codes
J6 / J61
ISO
FLC02CQ3AD$$$$
LF (Functional length)
90 mm
LOC-01 ISO
CCS01C0320****
LOC-01 (CCFWS Connection code form)
01
LOC-01 (CCSWS Connection code style)
5 Shaft in machine direction or hole in workpiece direction
LOC-01 (CCTWS Connection code type)
CCS Coromant Capto System SANDVIK
LOC-01 (CCUWS Connection code unit base)
9 non-dimensional size with coolant
LOC-01 (CZCWS Connection size code)
0320
LOC-01 (DCONWS Diameter)
32 mm
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
CCS03200195
LOC-02 ISO
CCS02C0320****
LOC-02 (CCFWS Connection code form)
01
LOC-02 (CCSWS Connection code style)
5 Shaft in machine direction or hole in workpiece direction
LOC-02 (CCTWS Connection code type)
CCS Coromant Capto System SANDVIK
LOC-02 (CCUWS Connection code unit base)
9 non-dimensional size with coolant
LOC-02 (CZCWS Connection size code)
0320
LOC-02 (DCONWS Diameter)
32 mm
LOC-02-Connection-codes
J4 / J431 - Workpiece end
LOC-02-DIN
CCS03200295
LOC-03 ISO
FLC02CQ3AD$$$$
LOC-03 (CCFMS Connection code form)
02
LOC-03 (CCSMS Connection code style)
5 Shaft in machine direction or hole in workpiece direction
LOC-03 (CCTMS Connection code type)
FLC Flange mounting SANDVIK Coromant
LOC-03 (CCUMS Connection code unit base)
9 non-dimensional size with coolant
LOC-03 (CZCMS Connection size code)
Q3AD
LOC-03 (DCONMS Diameter)
32 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
FLCQ3AD0295
LPR (Protruding length)
124 mm
OAH (Overall height)
78 mm
OAL (Overall length)
198.5 mm
OAW (Overall width)
104 mm
WF (Functional width)
45 mm
WT (Weight of item)
5.5 kg
