Главная Инструменты 401-02 - Converter, stationary C10-SL70-LG-100

C10-SL70-LG-100

C10-SL70-LG-100 C10-SL70-LG-100 C10-SL70-LG-100 C10-SL70-LG-100

C10-SL70-LG-100

SV - Sandvik-Coromant
Артикул: 5957922
В наличии
0 ₽
В корзину
Описание
Характеристики
CCFWS (Connection code form)
01
CCSWS (Connection code style)
7
CCTWS (Connection code type)
CMS
CCUWS (Connection code unit base)
9
CNSC (Coolant entry style code)
3 - With Coolant entry, axial concentric and radial
CXSC (Coolant exit style code)
1 - With Coolant exit, axial concentric
CXSC (Coolant exit style code) / Тип подвода СОЖ
1 - With Coolant exit, axial concentric
CZCWS (Connection size code)
0700
DCONWS (Diameter)
100 mm
DCONWS (Diameter) / Диаметр соединения со стороны заготовки
100 mm
DCP (Data chip provision)
0 - Without data chip
Delivery state
LH - Stocked
Delivery state valid from
12/1/2023
DIN
CCS10000195
HAND (Cutting direction)
L - Left
HF (Functional height)
0 mm
Interface codes
J6 / J61
ISO
CCS01C1000$$$$
LF (Functional length)
100 mm
LOC-01 ISO
CMS01C0700****
LOC-01 (CCFWS Connection code form)
01
LOC-01 (CCSWS Connection code style)
7 Serrated connection
LOC-01 (CCTWS Connection code type)
CMS Coromant Modular boring SANDVIK
LOC-01 (CCUWS Connection code unit base)
9 non-dimensional size with coolant
LOC-01 (CZCWS Connection size code)
0700
LOC-01 (DCONWS Diameter)
100 mm
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
CMS07000197
LOC-03 ISO
CCS01C1000$$$$
LOC-03 (CCFMS Connection code form)
01
LOC-03 (CCSMS Connection code style)
5 Shaft in machine direction or hole in workpiece direction
LOC-03 (CCTMS Connection code type)
CCS Coromant Capto System SANDVIK
LOC-03 (CCUMS Connection code unit base)
9 non-dimensional size with coolant
LOC-03 (CZCMS Connection size code)
1000
LOC-03 (DCONMS Diameter)
100 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
CCS10000195
LPR (Protruding length)
100 mm
OAH (Overall height)
70.5 mm
OAL (Overall length)
160 mm
OAW (Overall width)
118 mm
WF (Functional width)
48 mm
WT (Weight of item)
5.229 kg
