Главная Инструменты 308-02 - Shoulder milling cutter L260.42-400A-10

L260.42-400A-10

L260.42-400A-10

L260.42-400A-10

L260.42-400A-10

SV - Sandvik-Coromant

Артикул: 5735338

В наличии

0 ₽

В корзину

Описание

Характеристики

A1A (Cutting edge angle major Pos. A)

90 Degree

A2A (Clearance angle major Pos. A)

5 Degree

AZ (Plunge depth maximum)

0 mm

B3A (Inscribed circle diameter Pos. A)

12.7 mm

BD (Body diameter)

399.6 mm

BI (Block index)

1

BLDA (Tool style code Position A)

2

BMC (Body material code)

S - Solid steel

C1A (Insert thickness Pos. A)

3.175 mm

CCONMS (Connection count machine side)

2

CDX (Cutting depth maximum)

1 mm

CICT (Cutting item count)

40

CNSC (Coolant entry style code)

0 - Without coolant entry

CXSC (Coolant exit style code)

0 - Without coolant exit

CXSC (Coolant exit style code) / Тип подвода СОЖ

0 - Without coolant exit

DC (Cutting diameter)

400 mm

DCP (Data chip provision)

0 - Without data chip

Delivery state

LA - Soon discontinued

Delivery state valid from

12/1/2023

DIN

SPK25000523

F23 (Number of mounting layers)

1

F24 (Cutting item count per mounting layer)

40

GAMF (Rake angle radial)

-2 Degree

GAMP (Rake angle axial)

-4 Degree

HAND (Cutting direction)

L - Left

Interface codes

J6 / J61

ISISO A (Indicator for ISO cutting plate Pos.A)

1

ISO

SPK05S2500$$$$

KAPR (Tool cutting edge angle)

90 Degree

LOC-03 ISO

SPK05S2500$$$$

LOC-03 (CCFMS Connection code form)

05

LOC-03 (CCSMS Connection code style)

3 Hole pattern (through bore) machine side or hole pattern (threaded hole) machine side or

LOC-03 (CCTMS Connection code type)

SPK Spindle nose mounting

LOC-03 (CCUMS Connection code unit base)

2 Inch

LOC-03 (CZCMS Connection size code)

2500

LOC-03 (DCONMS Diameter)

63.5 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

SPK25000523

MIID (Master insert identification)

SBEX1203ZZ

OAL (Overall length)

63 mm

RMPX (Ramping angle maximum)

0 Degree

RPMX (Rotational speed maximum)

1250 1/min

Working process

FPL - Face milling

WT (Weight of item)

23.68 kg

ZEFF (Face effective cutting edge count)

40

ZEFP (Peripheral effective cutting edge count)

40
